Lenovo Legion Y540-17IRH-81Q4002CGE

Specifications

Lenovo Legion Y540-17IRH-81Q4002CGE
Lenovo Legion Y540-17IRH-81Q4002CGE (Legion Y540-17 Series)
Processor
Intel Core i7-9750H 6 x 2.6 - 4.5 GHz, Coffee Lake-H
Graphics adapter
NVIDIA GeForce RTX 2060 Mobile - 6 GB VRAM, GDDR6
Memory
16 GB
, DDR4-2666
Display
17.30 inch 16:9, 1920 x 1080 pixel 127 PPI, IPS, glossy: no
Storage
512GB M.2 PCIe + 1TB HDD
Connections
3 USB 3.0 / 3.1 Gen1, 1 HDMI, 1 DisplayPort, Audio Connections: 3.5mm, USB-C
Networking
10/100/1000 LAN Card (10/100/1000MBit/s), 802.11 a/b/g/n/ac (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 4.2
Size
height x width x depth (in mm): 26.3 x 400 x 290 ( = 1.04 x 15.75 x 11.42 in)
Battery
57 Wh Lithium-Ion, Battery runtime (according to manufacturer): 5 h
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD 720p
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes, 24 Months Warranty
Weight
2.84 kg ( = 100.18 oz / 6.26 pounds) ( = 0 oz / 0 pounds)
Price
1100 Euro



Pricecompare

Average Score: 85% - good
Average of 1 scores (from 2 reviews)

Reviews for the Lenovo Legion Y540-17IRH-81Q4002CGE

Lenovo Legion Y540 17" with RTX 2060 Full Review - Mid-range Gaming Laptop
Source: Lon.TV English Archive.org version
The current generation of Lenovo gaming laptops are nearing their end of life so you may be able to pick up one of these nicely performing machines for a good price!
Single Review, online available, Very Long, Date: 04/30/2020
85% Lenovo Legion Y540 review (RTX 2060 model, 17-inch screen)
Source: Ultrabook Review English Archive.org version
Lenovo did a very good job with their Legion Y540. Not only does this perform very well and leaves room for tweaking and overclocking, but it's also configurable and more affordable than most other options with similar features. However, it's not without quirks, and among them, you'll have to make do with the rather shallow keyboard, the small battery and its tinny speakers.
Single Review, online available, Very Long, Date: 12/09/2019
Rating: Total score: 85%

Comment

NVIDIA GeForce RTX 2060 Mobile: Mid range to high end laptop graphics card based on the Turing architecture with raytracing features and 1,920 shaders. Compared to the similar named desktop card it offers reduced clock rates.

With these GPUs you are able to play modern and demanding games fluently at medium detail settings and HD resolution.

» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i7-9750H: A high-performance hexa-core processor of the Coffee Lake product family designed for the larger laptops. Integrates six processor cores clocked at 2.6 - 4.5 GHz (4 GHz with 6 cores) that support HyperThreading. Manufactured in an improved 14nm process (14nm++).» Further information can be found in our Comparison of Mobile Processsors.


17.30": This display size is a standard format for desktop replacements (DTR). The DTR laptops are heavier to carry, need more power, but texts are easy to read and high resolutions are no problem. DTR are mainly intended for stationary desk use, where weight and energy hunger don't matter. In return, you enjoy the advantages of high resolutions (more details, better legibility).» To find out how fine a display is, see our DPI List.


2.84 kg:

With this weight, a laptop is rather heavier than average. Devices in this range shine more with screen size and performance than with mobility.


Lenovo: Lenovo ("Le" from English legend, novo (Latin) for new) was founded in 1984 as a Chinese computer trading company. As of 2004, the company was the largest laptop manufacturer in China and, after acquiring IBM's PC division in 2005, the fourth largest in the world. In addition to desktops and notebooks, the company manufactures monitors, projectors, servers, etc, and specializes in developing, manufacturing and marketing consumer electronics, personal computers, software, enterprise solutions and related services.

In 2016, the company ranked first in the world in computer sales. It still held it in 2023 with about 23% global market share. Important product lines are Thinkpad, Legion and Ideapad.

In 2011, it acquired a majority stake in Medion AG, a European computer hardware manufacturer. In 2014, Motorola Mobility was purchased, which gave Lenovo a boost in the smartphone market.


85%: This rating is slightly above average, there are somewhat more devices with worse ratings. However, clear purchase recommendations look different.


» Further information can be found in our Notebook Purchase Guide.
