Qualcomm Snapdragon 690 5G
The Qualcomm Snapdragon 690 5G (SD690) is a fast mid-range ARM-based SoC largely found on Android tablets and smartphones. It features 8 Kryo 560 called cores (64-Bit capable) that are divided in two clusters. A fast cluster of two cores with up to 2 GHz and based on the ARM Cortex-A77 design. And a power saving efficiency cluster with up to 1.7 GHz and based on much smaller ARM Cortex-A55 cores. Both clusters can also used together.
In addition to the 8 CPU cores, the SoC integrates a lower mid range Adreno 619L GPU , a X51 5G radio (up to 2.5 Gbits download, no mmWave), a 802.11ax (Wi-Fi 6, 8x8 sounding, WPA3, Dual Band, 2x2), a Bluetooth 5.1 radio, satellite positioning (GPS, QZSS, GLONASS, SBAS, Beidou and Galileo) and a video engine (support for H.265, H.264, VP8 and VP9).
Performance
Due to the two big A77 cores, the performance of the SoC in our benchmarks is on par with mid range SoCs like the Snapdragon 765 or the Dimensity 800U .
The Snapdragon 690 is produced in the 8nm LPP (Low Power Plus) process at Samsung.
Series Qualcomm Snapdragon Codename Kryo 560 Gold (Cortex-A77) / Silver (Cortex-A55) Clock Rate 1700 - 2000 MHz Number of Cores / Threads 8 / 8 Manufacturing Technology 8 nm Features Adreno 619L GPU, X51 5G Modem, Hexagon 692 DSP, Spectra 355L ISP GPU Qualcomm Adreno 619L 64 Bit 64 Bit support Architecture ARM Announcement Date 06/17/2020 Product Link (external) www.qualcomm.com
Benchmarks Performance Rating - Geekbench 5.5, PCM Work, Sling Shot Physics, Antutu v8 CPU
0.6 pt (49%)
...
Qualcomm Snapdragon 690 5G
...
3DMark - 3DMark Ice Storm Unlimited Physics
19976 Points (17%)
...
Qualcomm Snapdragon 690 5G
...
max:
3DMark - 3DMark Sling Shot Extreme (ES 3.1) Unlimited Physics
min: 3344 avg: 3359 median: 3359 (40%) max: 3374 Points
...
Qualcomm Snapdragon 690 5G
...
max:
3DMark - 3DMark Sling Shot (ES 3.0) Unlimited Physics
min: 2593 avg: 3289 median: 3288.5 (38%) max: 3984 Points
...
Qualcomm Snapdragon 690 5G
...
Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Single-Core
min: 590 avg: 600 median: 600 (25%) max: 610 points
...
Qualcomm Snapdragon 690 5G
...
max:
Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Multi-Core
min: 1716 avg: 1795 median: 1794.5 (3%) max: 1873 points
...
Qualcomm Snapdragon 690 5G
...
max:
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
min: 2662 avg: 2740 median: 2739.5 (27%) max: 2817 points
...
Qualcomm Snapdragon 690 5G
...
max:
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
min: 6273 avg: 6837 median: 6837 (8%) max: 7401 points
...
Qualcomm Snapdragon 690 5G
...
max:
Geekbench 4.0 - Geekbench 4.0 64 Bit Single-Core
2648 points (36%)
...
Qualcomm Snapdragon 690 5G
...
max:
Geekbench 4.0 - Geekbench 4.0 64 Bit Multi-Core
6274 points (15%)
...
Qualcomm Snapdragon 690 5G
...
max:
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
5921 points (9%)
...
Qualcomm Snapdragon 690 5G
...
max:
Geekbench 3 - Geekbench 3 64 Bit Single-Core
2265 points (34%)
...
Qualcomm Snapdragon 690 5G
...
Geekbench 2 - 32 Bit - Geekbench Stream
2479 Points (20%)
...
Qualcomm Snapdragon 690 5G
...
max:
Geekbench 2 - 32 Bit - Geekbench Memory
4352 Points (39%)
...
Qualcomm Snapdragon 690 5G
...
max:
Geekbench 2 - 32 Bit - Geekbench Floating Point
11863 Points (23%)
...
Qualcomm Snapdragon 690 5G
...
max:
Geekbench 2 - 32 Bit - Geekbench Integer
5836 Points (12%)
...
Qualcomm Snapdragon 690 5G
...
max:
Geekbench 2 - 32 Bit - Geekbench Total Score
7298 Points (19%)
...
Qualcomm Snapdragon 690 5G
...
max:
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 2506 avg: 7349 median: 7349 (9%) max: 12192 ms
...
Qualcomm Snapdragon 690 5G
...
Sunspider - Sunspider 1.0 Total Score *
481.5 ms (5%)
...
Qualcomm Snapdragon 690 5G
...
Octane V2 - Octane V2 Total Score
min: 4395 avg: 10631 median: 10630.5 (10%) max: 16866 Points
...
Qualcomm Snapdragon 690 5G
...
max:
WebXPRT 3 - WebXPRT 3 Score
min: 29 avg: 51.5 median: 51.5 (11%) max: 74 Points
...
Qualcomm Snapdragon 690 5G
...
max:
min: 55299 avg: 57173 median: 57172.5 (48%) max: 59046 Points
...
Qualcomm Snapdragon 690 5G
...
AnTuTu v8 - AnTuTu v8 MEM
min: 58041 avg: 61739 median: 61739 (50%) max: 65437 Points
...
Qualcomm Snapdragon 690 5G
...
AnTuTu v8 - AnTuTu v8 GPU
min: 61533 avg: 61812 median: 61811.5 (11%) max: 62090 Points
...
Qualcomm Snapdragon 690 5G
...
AnTuTu v8 - AnTuTu v8 CPU
min: 105940 avg: 106448 median: 106448 (39%) max: 106955 Points
...
Qualcomm Snapdragon 690 5G
...
AnTuTu v8 - AnTuTu v8 Total Score
min: 282385 avg: 287171 median: 287170 (28%) max: 291956 Points
...
Qualcomm Snapdragon 690 5G
...
Antutu v9 - AnTuTu v9 Total Score
344070 Points (21%)
...
Qualcomm Snapdragon 690 5G
...
Antutu v9 - AnTuTu v9 CPU
103794 Points (28%)
...
Qualcomm Snapdragon 690 5G
...
PassMark PerformanceTest Mobile V1 - PerformanceTest Mobile V1 CPU Tests
515836 Points (68%)
...
Qualcomm Snapdragon 690 5G
PCMark for Android - PCM f. Android Storage 2.0 score
15297 Points (27%)
...
Qualcomm Snapdragon 690 5G
...
PCMark for Android - PCM f. Android Work Score 3.0
8273 Points (38%)
...
Qualcomm Snapdragon 690 5G
...
max:
PCMark for Android - PCM f. Android Storage
4356 Points (9%)
...
Qualcomm Snapdragon 690 5G
...
PCMark for Android - PCM f. Android Work Score 2.0
min: 7356 avg: 7689 median: 7688.5 (50%) max: 8021 Points
...
Qualcomm Snapdragon 690 5G
...
PCMark for Android - PCM f. Android Work Score
10321 Points (52%)
...
Qualcomm Snapdragon 690 5G
...
max:
Power Consumption - Geekbench 5.5 Power Consumption 150cd *
3.1 Watt (1%)
...
Qualcomm Snapdragon 690 5G
...
max:
0 1 2 3 4 5 Tooltip Sony Xperia 10 III: Ø3.14 (0.646-5.32)
Power Consumption - Idle Power Consumption 150cd 1min *
0.6 Watt (1%)
Qualcomm Snapdragon 690 5G
...
max:
0 0.1 0.1 0.2 0.2 0.3 0.4 0.4 0.5 0.5 0.6 0.6 0.7 0.8 0.8 0.9 0.9 1 1.1 1.1 Tooltip Sony Xperia 10 III: Ø0.632 (0.551-1.167)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
